PEI (CL11) Polyeser Film/foil Capacitor (Inductive)
聚酯膜－箔式電容器（有感型）
★ FEATURE 特點：
· Small size,light weight and low cost · 體積極小，重量輕，價格便宜
· Dissipation Factor is small because of ·散逸因素因引腳直接點焊于極板而特別小
the leads are directly welded to the electrodes
· Epoxy resin vacuum-dipped enhance the ·真空條件下環氧樹脂含浸，加強機械強度，耐濕性
mechanical strength and humidity resistance
★APPLICATION 用途：
· Widely used in DC and pulsing circuits ·廣泛用于收音機、電視、各式電器設備中直流
of radio,TV sets and various electronic equipments 及脈沖 回路
· PEI is suitable for high voltage usage · PEI 適用于高壓用途，諸如節能燈，捕蚊燈
such as energy-saving lamp and mosquito-killer lamp
★SPECIFICATION S技術要求：
|
DIELECTRIC
介質
|
Polyester film
聚酯薄膜
|
|
ELECTRODES
電極
|
Aluminum foil
鋁箔極板
|
|
COATING
包封
|
Epoxy resin coating
環氧樹脂封裝
|
|
LEADS
導線
|
Radial leads of tinned wire
徑向鍍錫導線
|
|
REFERENCE STANDARD
引用標準
|
IEC 384-11 SJ/T10786-1996
|
|
CLIMATIC CATALOGUE
氣候類別
|
40/85/21 (From 85℃ up to 105℃ with derating voltage 1.25%/℃)
(85℃至105℃間按1.25%/℃遞減電壓)
|
|
CAPACITANCE VERSUS
RATED VOLTAGE(UR)
靜電容量與額定電壓
|
0.001μF-0.47μF/100VDC 0.001μF-0.27μF/250VDC
0.001μF-0.10μF/400VDC 0.001μF-0.047μF/1000VDC
|
|
CAPACITANCE TOLERANCE
靜電容量誤差
|
M=±20% K=±10% J=±5%
|
|
DISSIPATION FACTOR
（TANGENT OF LOSS）
散逸因素（損耗角正切）
|
≤1.0% （at 20℃,1KHz）
|
|
VOLTAGE PROOF
耐電壓
|
2.0*UR Unit:VDC (1minute at 20℃and RH≤65%)
|
|
INSULATION RESISTANCE
絕緣電阻
|
IR≥30000MΩ （1minute at 20℃ and RH≤65%）
|
|
ENDURANCE
耐久性
|
2000 hours with140% of rated voltage at 85℃.SAfter the Test :
85℃條件下，140%之額定電壓2000小時。試驗完成后：
△C/C≤5%；△DF≤1% ；IR≥50% of the specified value （標稱值）
（20℃ 1KHz）
|
